SPECIFICATIONS



Brand Name: TEyes

Din: One Din

Display Size: 9"

For Vehicle Brands/Model: JEEP

Digital Media Format: Mp3

Digital Media Format: MP4

Digital Media Format: WMA

Digital Media Format: JPEG

Special Feature: wifi function

Special Feature: Support steering wheel control

Certification: CE

Certification: EAC

Special Features: Built-in GPS

Special Features: Mobile Phone

Special Features: MP3 players

Operating System: Android

NOTE: Once the installation is done and everything is working, DON'T update the 4 canbus APK. Just leave it.

NOTE: Does not support heated steering (Beta Canbus update fix unconfirmed may resolve this)

NOTE: It does not support front/rear radar or blind spot detection.

NOTE: If the dashboard changes from Imperial to Metric or vice versa, put the old head unit back in, set it back, and replace it again.

Or

NOTE: If you need your vehicle to display Miles/per hour, then set it in your instrument panel settings.

NOTE: Trip distance, fuel range, and TPMS measurements will remain in metric

NOTE: We have been informed that this vehicle has an issue where the center controls of the OEM panel (volume, temp, ect) sometimes don't respond. This is not related to our unit. The solution is removing and replacing the F49 jumper in the fuse box.

WARNING!!: If you have a thin gap between the A/C controls and the bottom buttons, then Select F1 as the F2 frame is not compatible as the F2 frame bottom buttons are for lower factory units. Our frame is 17mm high in this section. Pay attention.

Below is an example of the thin gap that required an F1 frame

Below is an example of a wide gap, this is compatible with both F1 and F2 frames

NOTE: The settings below, if the sound is too high and cannot be adjusted, change from DVD AMP to just DVD

NOTE: This is compatible
